The ignition system of an internal-combustion engine is an important part of the overall engine system. It provides for the timely burning of the fuel mixture within the engine. more...

Not all engine types need an ignition system - for example, a diesel engine relies on compression-ignition, that is, the rise in temperature that accompanies the rise in pressure within the cylinder is sufficient to ignite the fuel spontaneously. All conventional petrol (gasoline) engines, by contrast, require an ignition system. The ignition system is usually switched on/off through a lock switch, operated with a key or code patch.

The earliest petrol engines used a very crude ignition system. This often took the form of a copper or brass rod which protruded into the cylinder, which was heated using an external source. The fuel would ignite when it came into contact with the rod. Naturally this was very inefficient as the fuel would not be ignited in a controlled manner. This type of arrangement was quickly superseded by spark ignition, a system which is generally used to this day, albeit with sparks generated by more sophisticated circuitry.

Glow plug ignition

Glow plug ignition is used on some kinds of simple engines, such as those commonly used for model aircraft. A glow plug is a coil of wire (made from e.g. nichrome) that will glow red hot when an electric current is passed through it. This ignites the fuel on contact, once the temperature of the fuel is already raised due to compression. The coil is electrically activated for engine starting, but once running, the coil will retain sufficient residual heat on each stroke due to the heat generated on the previous stroke. Glow plugs are also used to aid starting of diesel engines.

Magneto system

The simplest form of spark ignition is that using a magneto. The engine spins a magnet inside a coil, and also operates a contact breaker, interrupting the current and causing the voltage to be increased sufficiently to jump a small gap. The spark plugs are connected directly from the magneto output. Magnetos are not used in modern cars, but because they generate their own electricity they are often found on small engines such as mopeds, lawnmowers, snowblowers, chainsaws, etc. where there is no battery, and also in aircraft piston engines, where their simplicity and self-contained nature confers a generally greater reliability as well as lighter weight in the absence of a battery and generator or alternator. Aircraft engines usually have multiple magnetos to provide redundancy in the event of a failure. Some older automobiles had both a magneto system and a battery actuated system (see below) running simultaneously to ensure proper ignition under all conditions with the limited performance each system provided at the time.
